30kW Flatbed Laser Cutting Services
Cutting Capacity up to 60mm Thick Plates | Expert Metalworking with Advanced Fiber Laser Technology
High-Tech Sheet Metal Cutting
MMI offers precise flatbed laser cutting services using advanced fiber optic laser technologies. Our high-tech 30kW laser machine can handle both small and large production runs with tight tolerances and perfect repeatability. We guarantee precision cutting (±0.05mm/m) for various metal sheets and plates, with the ability to accommodate sheet sizes up to 6,100mm x 2,500mm.
30kW Cutting Process Package
Special fiber laser nozzle and cutting process ensure faster carbon steel oxygen cutting, more gas-saving low-pressure stainless-steel nitrogen cutting, and better-quality carbon steel air cutting with capacity up to 60mm thick plates.
Vision-sensing Anti-collision
Multi-dimension alert to guarantee safe processing. Dual protection methods in a real sense, reducing injury rates for customers.
Active Anti-collision Function
Fiber laser heads are able to detect cutting obstacles to effectively reduce the damage rate and save the maintenance cost of a laser cutter.
No Quiver when Cutting Thin Sheet
The cutting process works even at the edge of thin sheets, and ensures no chatter marks.
Lightning-Quick Piercing
The lightning-quick piercing process combined perfectly with BodorGenius completes the whole piercing just during the laser cutter head moves down on Z-axis.
One-Click Processing
With One-click Processing, one laser cutter is able to process multiple sheets in batches with a one-off setup, achieving batch processing.
Laser Cutting & Punching Services
Laser sheet metal cutting and punching services are advanced procedures used to shape and cut metal sheets based on your design specifications. They can be incredibly intricate and designed for cutting edges, windows, perforations, or just about anything.
Architectural & Decorative
Intricate patterns for facades, screens, and interior design elements
Industrial Components
Custom parts for machinery, equipment, and manufacturing
Structural Elements
Brackets, supports, and load-bearing components
Prototyping
Rapid production of prototypes and custom designs
Technical Data
- Working Area:6100mm × 2500mm
- Laser Output Power:30kW
- Max Cutting Capacity:Up to 60mm Thick Plates
- Laser Cutting Thickness:Up to 50mm
- Positioning Accuracy:±0.03mm/m
- Precision Cutting Accuracy:±0.05mm/m
- Repositioning Accuracy:±0.03mm
- Maximum Acceleration:1.3G
- Cutting Speed:Up to 200mm/s
Material Description
Mild Steel
0.5mm - 55mm Thickness
Versatile and cost-effective
Stainless Steel
0.5mm - 30mm Thickness
Corrosion-resistant finish
Aluminium
0.5mm - 25mm Thickness
Lightweight precision parts
Our Laser Cutting Capabilities
Precision up to 60mm
High-precision cutting through thick plates up to 60mm
30kW Laser Power
State-of-the-art 30kW Flat Bed Laser Machine
Minimal Material Waste
Optimized cutting paths for efficiency
Clean Edge Quality
Superior finish with no secondary processing
Fast Turnaround
Quick production without compromising quality
Quality Assured
ISO-certified processes and standards
Ready for Precision Laser Cutting?
Contact us today to discuss your laser cutting requirements and get a free quote
